Explosion Proof
Your current position: Home > PRODUCTS > Explosion Proof
PRODUCTS#FANWEI
· GroupⅡA,groupⅡB,groupⅡC of explosive gas environments,zone1 and zone2.
· GroupⅢA,groupⅢB,groupⅢC of combustible dust environments,zone21 and zone22.
PRODUCTS#TEDIAN
· Die-casting alloy shell with high pressure electrostatic powder spray, high strength and corrosion resistance.
· Flameproof enclosure with spigot joints and threaded joints, reliable explosion-proof performances.
· Silicone rubber sealed, excellent performance of protection and ageing-resistance , adapt to kinds of awful environments.
· High-quality LED, high luminous efficiency, good color rendering, anti-impact and vibration resistance.
· Non-imaging secondary optical design, adjustable radiation angle, spotlighting for different distances or ranges.
· Constant current drive, wide range input, isolated input/output, intelligent protective circuit, run reliably.
PRODUCTS#JISHU
型號Type | AK-LBTR80(LT) |
系統功率Power | 80W |
輸入電壓Input Voltage | AC110~264V 50~60Hz |
配光Light Distribution | 寬光 Wide Beam窄光 Narrow Beam |
系統輸出System Output | ≥7600lm |
系統光效System Luminous Efficency | ≥95lm/W |
顯色指數Color Rendering Index | ≥80 |
色溫Color Temperature | 2700~6500K |
透明罩Transparent Cover | 高強度鋼化玻璃 Tempered Glass |
進線口螺紋Cable Gland Thread | G3/4” |
電纜外徑Cable External Diameter | 8~12mm |
防護等級Degree of Protection | IP66 |
防腐等級Degree of Corrosion-proof | WF2 |
防爆標志Ex-mark | Ex d ll C T6 GbEx tD A21 IP66 T80℃ |
重量Weight | 6.6kg |
執行標準Implementing Standard | GB3836.1 GB3836.2 GB12476.1 GB12476.5 |
PRODUCTS#XUAN
序號S/N | 型號Type | 功率Power | 環境溫度Environment Temperature | 應急Emergency |
1 | AK-LBTR80-WB | 80W | -20℃～40℃ | - |
2 | AK-LBTR80-NB | 80W | -20℃～40℃ | - |
3 | AK-LBTR80-WB-LT | 80W | -45℃～40℃ | - |
4 | AK-LBTR80-NB-LT | 80W | -45℃～40℃ | - |
PRODUCTS#TIHUAN
